| General |
| Brand |
ASUS |
| Model |
Asus ROG STRIX X870E-E GAMING (Wi-Fi 7) |
| Part No |
ROG STRIX X870E-E GAMING WIFI |
| CPU |
| Chipset Brand |
AMD |
| Chipset |
AMD X870E |
| Sockets Supported |
AM5 |
| Built-in Processor |
No |
| Generation |
Not Applicable |
| Supported CPU |
AM5 for AMD Ryzen 9000 & 8000 & 7000 Series Desktop Processors |
| Memory & Storage Support |
| Memory Type |
DDR4 |
| Memory MHz |
8000(O.C)/ 7950(O.C)/ 7900(O.C)/ 7800(O.C)/ 7600(O.C.)/ 7400(O.C.)/ 7200(O.C.)/ 7000(O.C.)/ 6800(O.C.)/ 6600(O.C.)/ 6400(O.C.)/ 62
00(O.C.)/ 6000(O.C.)/ 5800(O.C.)/ 5600(O.C.)/ 5400(O.C.)/ 5200(O.C.)/ 4800/ 4000 MHz ECC & non-ECC Un-buffered memory with Ryzen 9
000 Series Processors/ 8400+MT/s(OC) with Ryzen 8000 Series Processors/ 8000+MT/s(OC) with Ryzen 7000 Series Processors |
| Memory Channel |
Dual |
| Memory Slot |
4 |
| Memory Max. |
192GB |
| Graphics |
| Graphics Chipset |
Integrated With Processor |
| PCI Express Slot |
1 x PCIe 5.0 x16 SafeSlot, 1 x PCIe 4.0 x16 Slots (x4) |
| Multi-GPU Support |
No |
| Ports |
| USB Port |
2 x USB4 (40Gbps) ports (2 x USB Type-C), 1 x USB 20Gbps port (1 x USB Type-C with up to 30W PD Fast-charge), 10 x USB 10Gbps port
s (9 x Type-A + 1 x USB Type-C) |
| VGA Port |
No |
| DVI Port |
No |
| HDMI Port |
1 |
| DisplayPort (DP) |
No |
| SATA Port |
4 |
| Thunderbolt |
No |
| Network & Connectivity |
| LAN Chipset |
1 x Realtek 5Gb Ethernet |
| LAN Speed (Mbps) |
100/ 1000/ 2500Mbps/ 5Gbps |
| WiFi |
Yes |
| Bluetooth |
Bluetooth 5.4 |
| WiFi Technology |
Wi-Fi 7 |
| Audio |
| Audio Chipset |
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC ALC4080 |
| Audio Channel |
7.1 |
| Software |
| Supported Operating System |
Windows 11 |
| Technical Info |
| Back-Connect Design |
No |
| Cable Management |
Front |
| Heatsink |
Yes |
| RGB Support |
RGB |
| RGB Sync |
Aura Sync |
| Approx. Power Consumption |
70W |
| Form Factor |
ATX |
| Warranty Details |
| Warranty |
3 Year |
| Warranty Condition |
3 Year Replacement |
| Additional Info |
| Country Of Origin |
Taiwan |
| Made in/ Assemble |
China |
| Feature |
The ROG Strix X870E-E Gaming WiFi is engineered to harness the full potential of AMD Ryzen 9000 Series processors. Featuring PCIe
5.0 support, AI Overclocking, AI Cooling II, AI Networking II, and AEMP, setup is streamlined while performance is maximized. Dual
USB4 Type-C ports and WiFi 7 with Realtek 5Gb Ethernet ensure top-tier connectivity, while robust heatsinks keep M.2 drives cool
under heavy loads. This motherboard not only meets the demands of gaming and professional applications but also delivers the power
and connectivity essential for advanced AI PC applications. |
| Others Info |
Internal I/O Connectors: Fan and Cooling related: 1 x 4-pin CPU Fan header, 1 x 4-pin CPU OPT Fan header, 1 x 4-pin AIO Pump heade
r, 5 x 4-pin Chassis Fan headers, Power related: 1 x 24-pin Main Power connector, 2 x 8-pin +12V CPU Power connectors, Storage rel
ated: 5 x M.2 slots (Key M) , 4 x SATA 6Gb/s ports, USB: 1 x USB 20Gbps connector (supports USB Type-C), 2 x USB 5Gbps headers sup
port additional 4 USB 5Gbps ports, 3 x USB 2.0 headers support additional 6 USB 2.0 ports , Miscellaneous: 3 x Addressable Gen 2 h
eaders, 1 x CPU Over Voltage jumper, 1 x FlexKey button , 1 x Front Panel Audio header (F_AUDIO), 1 x Start button, 1 x 10-1 pin S
ystem Panel header, 1 x Thermal Sensor header, Special Features: Extreme Engine Digi+, ASUS Q-Design, ASUS Thermal Solution, ASUS
EZ DIY, Aura Sync, Manageability: WOL by PME, PXE, Accessories: Cables: 2 x SATA 6Gb/s cables, Additional Cooling Kit: 1 x Thermal
pad for M.2 22110, Miscellaneous: 1 x ASUS Wi-Fi moving antennas , 1 x Cable ties pack, 1 x M.2 Q-Latch package, 2 x M.2 Q-Slides
, 1 x ROG key chain, 1 x ROG Strix stickers, 5 x M.2 Rubbers, Documentation: 1 x Quick start guide |
| Bios Information |
| BIOS Type |
256 Mb Flash ROM |
| BIOS Model |
UEFI AMI BIOS |
