| General |
| Brand |
ASUS |
| Model |
Asus ProArt X870E-CREATOR (Wi-Fi 7) |
| Part No |
ProArt X870E-CREATOR WIFI |
| CPU |
| Chipset Brand |
AMD |
| Chipset |
AMD X870E |
| Sockets Supported |
AM5 |
| Built-in Processor |
No |
| Generation |
Not Applicable |
| Supported CPU |
Ryzen 9000 & 8000 & 7000 Series Desktop Processors |
| Memory & Storage Support |
| Memory Type |
DDR5 |
| Memory MHz |
8000+(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/
5200/ 5000/ 4800 ECC and Non-ECC, Un-buffered Memory |
| Memory Channel |
Dual |
| Memory Slot |
4 |
| Memory Max. |
192GB |
| Storage Interface |
6.0Gb/s |
| M.2/SSD Expansion Slot |
4 |
| M.2/SSD Expansion Slot Details |
4 x M.2 (2 x M.2, type 2242/2260/2280 (supports PCIe 5.0 x4 mode), 1 x M.2, type 2242/2260/2280 (supports PCIe 4.0 x4 mode), 1 x M
.2, type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode)) |
| M.2/SSD Slot Gen |
Up to Gen 5 |
| Graphics |
| Graphics Chipset |
Integrated With Processor |
| PCI Express Slot |
2 x PCIe 5.0 x16 slots, 1 x PCIe 4.0 x16 slot |
| Multi-GPU Support |
No |
| Ports |
| USB Port |
2 x USB4 (40Gbps) port(s) (2 x USB Type-C), 1 x USB 20Gbps port (1 x USB Type-C), 7 x USB 10Gbps ports (7 x Type-A), 1 x USB 2.0 p
ort (1 x Type-A) |
| VGA Port |
No |
| DVI Port |
No |
| HDMI Port |
1 |
| DisplayPort (DP) |
1 |
| SATA Port |
4 |
| Thunderbolt |
No |
| Network & Connectivity |
| LAN Chipset |
Marvell AQtion 10Gb Ethernet & Intel 2.5Gb Ethernet |
| LAN Speed (Mbps) |
100/ 1000/ 2500Mbps/ 10Gb |
| WiFi |
Yes |
| Bluetooth |
Bluetooth 5.4 |
| WiFi Technology |
Wi-Fi 7 |
| Audio |
| Audio Chipset |
Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC* |
| Audio Channel |
7.1 |
| Software |
| Supported Operating System |
Windows 11 |
| Technical Info |
| Back-Connect Design |
No |
| Cable Management |
Front |
| Heatsink |
Yes |
| RGB Support |
No |
| Approx. Power Consumption |
70W |
| Form Factor |
ATX |
| Warranty Details |
| Warranty |
3 Year |
| Warranty Condition |
3 Year Replacement |
| Additional Info |
| Country Of Origin |
Taiwan |
| Made in/ Assemble |
China |
| Feature |
ASUS 5X PROTECTION III, ASUS Q-Design, ASUS Thermal Solution, AURA Sync, Bespoke Motherboard Design & Business Focused Features, F
ront Panel USB 20Gbps with Quick Charge 4+ Support, ASUS Exclusive Software, UEFI BIOS, IT Management software supported |
| Bios Information |
| BIOS Type |
256 Mb Flash ROM |
| BIOS Model |
UEFI AMI BIOS |
