| General |
| Brand |
MERCUSYS |
| Model |
Mercusys MR20 |
| Router Type |
Wireless & Ethernet |
| Physical Description |
| Power |
9V - 0.6A = 5.4 watt |
| Button |
Reset/WPS Button |
| Color |
White |
| Hardware & Network |
| Ethernet (LAN) Standard |
10/100 |
| Data Transfer Rate (Wifi) |
750 Mbps |
| Network Standards |
11ac/a/b/g/n |
| WiFi (WAN) Network Standards |
954 |
| Data Transfer Rate (LAN) |
100 Mbps |
| Interface(s) |
1x 10/100 Mbps WAN Port, 2x 10/100 Mbps LAN Ports |
| Number of WAN Port |
1 |
| Number of LAN Port |
2 |
| Internet Connectivity |
WAN Only |
| SIM Card |
No |
| Operation/Working Wireless Modes |
Router Mode, Range Extender Mode, Access Point Mode |
| Additional Info |
| Others |
300 Mbps (2.4 GHz) + 433 Mbps (5 GHz), 2.4G: 11g 6Mbps: -94dBm, 11g 54Mbps: -77dBm, 11n HT40 MCS7:-73dBm, 11n HT20 MCS7:-76dBm. 5G
: 11a 6Mbps:-93dBm, 11a 54Mbps:-75dBm, 11ac VHT20 MCS8:-70dBm, 11ac VHT40 MCS9:-65dBm, 11ac VHT80 MCS9:-62dBm. Transmission P |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Security |
| Encryption Type / Security Protocols |
WPA-PSK / WPA2-PSK |
| Firewall Protocols |
SPI Firewall, IP and MAC Address Binding |
| VPN Support |
No |
| Built in Antivirus |
No |
| Wireless |
| Antenna (Type & Qty) |
2 x 5 dBi Fixed Omni-Directional Antennas |
| WAN Type |
Dynamic IP/Static IP/PPPoE/L2TP/PPTP |
| Wi-Fi Generation |
Wi-Fi 5 |
| Band |
Dual Band |
| Wi-Fi Coverage (Approximate) |
Up to 1500 sq. ft. |
| Mesh Technology |
No |
| MIMO Technology |
No |
| Operating Frequency |
2.4 GHz, 5 GHz |
| Warranty Details |
| Warranty |
1 Year |
| Warranty Condition |
Without Adapter |
