| General |
| Brand |
MERCUSYS |
| Model |
Mercusys AC12G |
| Router Type |
Wireless & Ethernet |
| Physical Description |
| Power |
12V/1A |
| Button |
WPS/Reset Button |
| Color |
Black |
| Hardware & Network |
| Ethernet (LAN) Standard |
10/100/1000 |
| Data Transfer Rate (Wifi) |
1300 Mbps |
| Network Standards |
IEEE 802.11a/n/ac 5 GHz, IEEE 802.11b/g/n 2.4 GHz |
| WiFi (WAN) Network Standards |
953 |
| Data Transfer Rate (LAN) |
100 Mbps |
| Interface(s) |
1 x 10/100/1000 WAN, 3 x 10/100/1000 LAN |
| Number of WAN Port |
1 |
| Number of LAN Port |
3 |
| Internet Connectivity |
WAN Only |
| SIM Card |
No |
| Operation/Working Wireless Modes |
Router |
| Additional Info |
| Others |
Reception Sensitivity: 5 GHz: 11a 6M: -92 dBm, 11a 54M: -75 dBm, 11ac 20M MCS8: -70 dBm, 11ac 40M MCS9: -64 dBm, 11ac 80M MCS9: -6
0 dBm, 2.4 GHz: 11g 6M: -95 dBm, 11g 54M: -77 dBm, 11n 20M MCS7: -74 dBm, 11n 40M MCS7: -71 dBm, Transmission Power: < |
| Specialty |
AC12G is compatible with EasyMesh, enabling you to set up a whole home mesh network with one WiFi name and password with any other
APs that support EasyMesh from multiple vendors. Enjoy flexible, scalable, and seamless mesh WiFi throughout your home. |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Security |
| Encryption Type / Security Protocols |
IPv4, IPv6 |
| Firewall Protocols |
IP and MAC Address Binding |
| VPN Support |
No |
| Built in Antivirus |
No |
| Wireless |
| Antenna (Type & Qty) |
4 x External Antenna |
| WAN Type |
Dynamic IP/ Static IP/ PPPoE/ PPTP/ L2TP |
| Wi-Fi Generation |
Wi-Fi 5 |
| Band |
Dual Band |
| Wi-Fi Coverage (Approximate) |
Up to 1500 Sq. ft |
| 3G/4G |
No |
| Mesh Technology |
No |
| MIMO Technology |
No |
| Operating Frequency |
2.4 GHz, 5 GHz |
| Warranty Details |
| Warranty |
1 Year |
| Warranty Condition |
Without Adapter |
