| General |
| Brand |
MERCUSYS |
| Model |
Mercusys AC12 |
| Router Type |
Wireless & Ethernet |
| Physical Description |
| Power |
9V/0.85A |
| Button |
WPS/ Reset Button |
| Color |
Black |
| Hardware & Network |
| Ethernet (LAN) Standard |
10/100 |
| Data Transfer Rate (Wifi) |
1200 Mbps |
| Network Standards |
IEEE 802.11b,g,n,ac, IEEE 802.3,3u |
| WiFi (WAN) Network Standards |
954 |
| Data Transfer Rate (LAN) |
100 Mbps |
| Interface(s) |
1 x 10/100 RJ45 WAN, 3 x 10/100 RJ45 LAN |
| Number of WAN Port |
1 |
| Number of LAN Port |
3 |
| USB Interface |
No |
| Internet Connectivity |
WAN Only |
| SIM Card |
No |
| Operation/Working Wireless Modes |
Router, Range Extender, Access Point |
| Additional Info |
| Others |
WiFi Speeds: 300Mbps at 2.4GHz, 867Mbps at 5GHz, Reception Sensitivity: 5GHz: 11a 6M: -92dBm, 11a 54M: -75dBm, 11ac 20M MCS8: -70d
Bm, 11ac 40M MCS9: -64dBm, 11ac 80M MCS9: -60dBm, 2.4GHz: 11g 6M: -95dBm, 11g 54M: -77dBm, 11n 20M MCS7: -74dBm, 11n 40M MCS7 |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Security |
| Encryption Type / Security Protocols |
WPA-PSK / WPA2-PSK |
| Firewall Protocols |
IP and MAC address binding |
| VPN Support |
No |
| Built in Antivirus |
No |
| Voice Assistant |
No |
| Wireless |
| Antenna (Type & Qty) |
4 x 5dBi omni directional antennas |
| WAN Type |
Dynamic IP/ Static IP/ PPPoE/ L2TP/ PPTP |
| Wi-Fi Generation |
Wi-Fi 5 |
| Band |
Dual Band |
| Wi-Fi Coverage (Approximate) |
Up to 1500 sq. ft. |
| 3G/4G |
No |
| Mesh Technology |
No |
| MIMO Technology |
Yes |
| Operating Frequency |
2.5 GHz, 5.2 GHz |
| Warranty Details |
| Warranty |
1 Year |
