| General |
| Brand |
Hikvision |
| Model |
Hikvision DS-7764NI |
| Type |
8K NVR |
| Physical Description |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Approx. Power Consumption |
< 15W (without HDD) |
| Color |
Black |
| Dimensions |
445 x 400 x 75mm |
| Weight (KG) |
< 5 kg (without HDD) |
| Recording & Network |
| Dual Stream Support |
Yes |
| Decoding Capability |
2-ch@32 MP (30 fps)+2-ch@8MP (30fps) /10-ch@8 MP (30 fps)/20-ch@4 MP (30 fps)/40-ch@1080p (30 fps) |
| Synchronous Playback |
16-ch |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Wi-Fi |
No |
| Network Interface (RJ45) |
2 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interfaces |
| POE Interface |
No |
| Video & Audio |
| Number of Input Channel |
64 Channel |
| Video Compression/Format |
H.265+/H.265/H.264+/H.264 |
| Video Output (VGA) |
1920 x 1080/60Hz, 1600 x 1200/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
| Video Output (HDMI) |
8K (7680 x 4320)/30Hz, 4K (3840 x 2160)/60Hz, 4K (3840 x 2160)/30Hz, 2K (2560 x 1440)/60Hz, 1920 x 1080/60Hz, 1600 x 1200/60Hz, 12
80 x 1024/60Hz, 1280 x 720/60Hz, 1024 x 768/60Hz |
| Video Output (BNC) |
No |
| Video Recording Res |
7680 x 4320 |
| IP Video Input |
64 Channel |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2 |
| Audio Output Channel |
1-ch |
| Technical Info |
| Number HDD Interface (SATA) |
4 SATA |
| Max HDD Support (GB,TB) |
Up to 16TB capacity for each HDD |
| Max. Storage Support |
16TB |
| eSATA |
1 eSATA |
| Serial Interface |
2 RS-485 (half-duplex), 1 RS-232 |
| USB Port |
Front panel: 2 x USB 2.0, Rear panel: 1 x USB 3.0 |
| Incoming Bandwidth |
400 Mbps |
| Outgoing Bandwidth |
400 Mbps |
| Smart Phone Supported |
Yes |
| Warranty Details |
| Warranty |
2 Year |
| Warranty Condition |
2 Year (Without Adapter) |
| Additional Info |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
