| General |
| Brand |
Hikvision |
| Model |
Hikvision DS-7616NXI-K1/VPro |
| Type |
NVR |
| Physical Description |
| Power Supply |
12 VDC, 1.5 A |
| Approx. Power Consumption |
<=10W |
| Color |
Black |
| Dimensions |
319 x 239 x 48 mm |
| Weight (KG) |
<=1 kg |
| Recording & Network |
| Dual Stream Support |
Unmentioned |
| Decoding Capability |
AI on: 12-ch@1080p (30 fps), AI off: 24-ch@1080p (30 fps) |
| Synchronous Playback |
16-ch |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP, HTTP, HTTPS |
| Network Interface (RJ45) |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| POE Interface |
No |
| Video & Audio |
| Number of Input Channel |
16 Channel |
| Video Compression/Format |
H.265, H.265+, H.264, H264+ |
| Video Output (VGA) |
1080P (1920x1080)/60Hz, UXGA (1600x1200)/60Hz, SXGA (1280x1024)/60Hz, 720P (1280x720)/60Hz |
| Video Output (HDMI) |
4K (3840x2160)/30Hz, 2K(2560x1440)/60Hz, 1080P (1920x1080)/60Hz, UXGA (1600x1200)/60Hz, SXGA (1280x1024)/60Hz, 720P (1280x720)/60H
z |
| Video Recording Res |
Recording Resolution 12 MP/8 MP/6 MP/5 MP/4 MP/3 |
| Max. Video Recording Res |
1920 x 1080 |
| IP Video Input |
16-ch |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2 |
| Audio Output Channel |
1-ch, RCA (Linear, 1 Kohm) |
| Technical Info |
| Number HDD Interface (SATA) |
1 SATA |
| Max. Storage Support |
16TB |
| USB Port |
Front panel: 1 x USB 2.0; Rear panel: 1 x USB 2.0 |
| Incoming Bandwidth |
160 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| Warranty Details |
| Warranty |
2 Year |
| Warranty Condition |
2 Year (Without Adapter) |
