| General |
| Brand |
Hikvision |
| Model |
Hikvision DS-7104HGHI-M1/T |
| Type |
DVR |
| Physical Description |
| Color |
White |
| Dimensions |
200 x 200 x 48mm |
| Weight (Kg) |
0.8 kg |
| Power Supply |
12 VDC, 1.5 A |
| Approx. Power Consumption |
<-10 W (without HDD) |
| Recording & Network |
| Stream Type |
Main stream, Sub stream |
| Dual Stream Support |
Yes |
| Synchronous Playback |
4-ch |
| Network Protocol |
TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP, HTTPS |
| Wi-Fi |
No |
| Network Interface (RJ45) |
1 x RJ45 10/100 Mbps self-adaptive Ethernet interface |
| Remote Connections |
32 |
| Video & Audio |
| Number of Input Channel |
04 Channel |
| Video Compression/Format |
H.265 Pro+/ H.265 Pro/ H.265/ H.264+/ H.264 |
| Video Output (VGA) |
1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz |
| Video Output (HDMI) |
1-ch, 1920 x 1080/60Hz, 1280 x 1024/60Hz, 1280 x 720/60Hz |
| Video Recording Res |
1080p, 720p |
| Max. Video Recording Res |
1080p |
| Video Bit Rate |
32 Kbps to 4 Mbps |
| IP Video Input |
1-ch (up to 5-ch) |
| Analog & HD-TVI Video Input |
4-ch |
| Audio Input Channel (RCA) |
1-ch RCA (2.0 Vp-p, 1 Kohm) |
| Audio Compression |
G.711u |
| Audio Output Channel |
1-ch, RCA (Linear, 1 K ohm) |
| Two way Audio |
Reuse the first audio input |
| Audio Bit Rate |
64 Kbps |
| Technical Info |
| CVBS Input |
Support |
| Video Detection |
Motion Detection 2.0 |
| Warranty Details |
| Warranty |
2 Year |
| Warranty Condition |
2 Year (Without Adapter) |
| Additional Info |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
