| General |
| Brand |
Hikvision |
| Model |
DS-2CD1347G3-LIU |
| Usage |
Outdoor |
| Type |
Turret IP Camera |
| Lens |
| Number of Lens |
Single Lens (Primary) |
| Lens |
2.8mm Fixed lens |
| Lens Mount |
M12 |
| Lens Adjustment Range |
Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360° |
| Focal Length |
2.8 mm / 4 mm |
| PTZ |
No |
| Viewing Angle. |
Horizontal FOV 95.7°, Vertical FOV 51.7°, Diagonal FOV 113.7° (For 2.8mm) |
| Physical Description |
| Form-Factor |
Turret |
| Smart Alarm |
Motion detection (human and vehicle classification), video tampering alarm, exception |
| Card Slot |
No |
| Storage Type |
N/A |
| Body Material |
Network Attached Storage |
| Color |
White |
| Dimensions |
110 mm x 102.7mm |
| Weight (gm) |
Approx. 365 gm |
| Power |
12 VDC -/+25%, 0.52 A, 5.5 mm coaxial power plug, reverse polarity protection, PoE: IEEE 802.3af, Class 3 |
| Battery Capacity |
N/A (Does not use batteries) |
| Battery Backup |
No |
| Battery Backup Time |
No |
| Approx. Power Consumption |
6.2W, 7.5W (PoE) |
| Operating Temperature |
-30 Degree C to 60 Degree C |
| Storing/Storage Temperature |
-30 Degree C to 60 Degree C |
| Operating Humidity |
95% or less (non-condensing) |
| Storing/Storage Humidity |
95% or less (non-condensing) |
| Network & Connectivity |
| Sim Supported |
No |
| Sim Network Type |
N/A |
| Interface(s) |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Wi-Fi |
No |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonj
our, SSL/TLS, ISAPI, SDK, ONVIF (Profile S, Profile G) |
| Camera & Other Details |
| Number of Camera |
1 |
| Camera Type |
Fixed IP Camera |
| Mega Pixels (MP) |
4.0 MP |
| Max. Camera Resolution |
2560 × 1440 |
| Secondary Camera Type |
N/A |
| Secondary Camera Mega Pixel (MP) |
N/A |
| Sensor Type. |
1/3" Progressive Scan CMOS |
| Resolution |
4MP (2560 × 1440), 1080P (1920 × 1080), 720P (1280 × 720) |
| Shutter Speed |
1 s to 1/100,000 s |
| Day & Night |
IR Cut Filter |
| Night Vision |
Yes |
| Night Vision Mode |
Color |
| S/N Ratio |
≥ 52 dB |
| Scanning System |
Progressive |
| Video Type |
Main stream: H.265+/H.265/H.264+/H.264, Sub-stream: H.265/H.264/MJPEG |
| Mic & Speaker |
Only Mic |
| Audio Communication |
One-Way Audio (Listen In Only) |
| Ingress Protection Grade |
IP67 |
| Working Distance |
63 Meter |
| Image |
| Dual-Stream |
Yes |
| Frame Rate |
25 fps, 24 fps |
| Noise Reduction |
Yes |
| Wide Dynamic Range (WDR) |
3D DNR |
| Security |
| Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for
Open Network Video Interface, security audit log, host authentication (MAC address) |
| Watermark |
Yes |
| Motion Detection |
Yes |
| Human Detection |
Yes |
| Dust Protection |
Yes |
| Water Protection |
Yes |
| Weather Proof |
Yes |
| Warranty Details |
| Warranty |
2 Year |
| Warranty Condition |
Without Adapter |
| Additional Info |
| Specialty |
ColorVu 3.0 technology for 24/7 clear colorful imaging, Smart Hybrid Light system, HikAI-ISP for industry-leading noise reduction,
Motion Detection 3.0 for exact human/vehicle categorization |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
