| General |
| Brand |
Hikvision |
| Model |
Hikvision DS-2CD1047G3-LIU |
| Usage |
Outdoor |
| Type |
Bullet Network Camera |
| Lens |
| Number of Lens |
Single Lens (Primary) |
| Lens |
Fixed focal lens 4mm |
| Lens Mount |
M12 |
| Lens Adjustment Range |
Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Focal Length |
2.8mm / 4mm (Variant Dependent) |
| PTZ |
No |
| Viewing Angle. |
Horizontal FOV 79.6 Degree, vertical FOV 43.2 Degree, diagonal FOV 93.2 Degree |
| Physical Description |
| Form-Factor |
Bullet |
| Smart Alarm |
Motion Detection 3.0 (Human and Vehicle classification), Video Tampering Alarm, Exception |
| Card Slot |
Yes |
| Storage Type |
N/A |
| Body Material |
Metal + Plastic |
| Color |
White |
| Dimensions |
69.1 x 66.9 x 172.9mm |
| Weight (gm) |
330gm |
| Power |
12 VDC ± 25% or PoE: IEEE 802.3af, Class 3 |
| Battery Capacity |
N/A |
| Battery Backup |
No |
| Battery Backup Time |
Not Applicable |
| Approx. Power Consumption |
Max. 7W (12 VDC) / 8W (PoE) |
| Operating Temperature |
-30 °C to 60 °C |
| Storing/Storage Temperature |
-30 °C to 60 °C |
| Operating Humidity |
95% or less (non-condensing) |
| Storing/Storage Humidity |
95% or less |
| Network & Connectivity |
| Sim Supported |
No |
| Sim Network Type |
N/A |
| Interface(s) |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Wi-Fi |
No |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonj
our, SSL/TLS, WebSocket, WebSockets |
| Camera & Other Details |
| Number of Camera |
1 |
| Camera Type |
Bullet IP Camera |
| Mega Pixels (MP) |
4.0 |
| Max. Camera Resolution |
2560 × 1440 |
| Secondary Camera Type |
N/A |
| Secondary Camera Mega Pixel (MP) |
N/A |
| Sensor Type. |
1/3" Progressive Scan CMOS |
| Resolution |
2560 × 1440 |
| Shutter Speed |
1 s to 1/100,000 s |
| Day & Night |
24/7 Full-Color Imaging |
| Night Vision |
Yes |
| Night Vision Mode |
Color |
| S/N Ratio |
>=52 dB |
| Scanning System |
Progressive |
| Video Type |
Main stream: H.265+/ H.265/ H.264+/ H.264, Sub-stream: H.265/ H.264/ MJPEG |
| Mic & Speaker |
Only Mic |
| Audio Communication |
One-Way Audio (Listen-In via Built-in Mic) |
| Ingress Protection Grade |
IP67 |
| Working Distance |
77 Meter |
| Image |
| Dual-Stream |
Yes |
| Frame Rate |
25 fps, 24 fps |
| Noise Reduction |
3D DNR (HikAI-ISP Enhanced) |
| Wide Dynamic Range (WDR) |
120 dB |
| Security |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authenticatio
n for HTTP/HTTPS, TLS 1.2, WSSE and digest authentication for Open Network Video Interface |
| Watermark |
Yes |
| Motion Detection |
Yes |
| Human Detection |
Yes |
| Dust Protection |
Yes |
| Water Protection |
Yes |
| Weather Proof |
Yes |
| Warranty Details |
| Warranty |
1 Year |
| Warranty Condition |
Covers manufacturing defects only. Physical damage, burn, or unauthorized modification will void the warranty. |
| Additional Info |
| Specialty |
ColorVu 3.0 technology for full-color night imaging, Smart Hybrid Light system switches dynamically from IR to visible light upon
target detection, HikAI-ISP noise reduction algorithm, and Motion Detection 3.0 focusing accurately on human and vehicle targets. |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
