| General |
| Brand |
Gigabyte |
| Model |
Gigabyte P750BS |
| PSU Category |
Non Modular |
| Type |
ATX 12V |
| Physical Description |
| MTBF |
>100,000 hours |
| Form Factor |
ATX |
| Dimensions |
150 x 140 x 86mm |
| Color |
Black |
| Performance & Protection |
| Efficiency |
88% Efficiency |
| Efficiency Rating |
80 Plus Bronze |
| PFC (Power Factor Correction) |
Active PFC (>0.9 typical) |
| Power Good Signal |
100-150ms |
| Hold Up Time |
>16ms |
| Protection |
OVP/OPP/SCP/UVP/OCP/OTP |
| Over Voltage Protection (OVP) |
Yes |
| Over Power Protection (OPP) |
Yes |
| Over Current Protection (OCP) |
Yes |
| Over Temperature Protection (OTP) |
Yes |
| Short Circuit Protection (SCP) |
Yes |
| Under Voltage Protection (UVP) |
Yes |
| Connectors, Features & Power |
| ATX Main Connectors |
1 |
| PCIe Connectors |
4 |
| SATA Power Connectors |
7 |
| 4-Pin Peripheral Connectors |
1 |
| Min. Power (Approx.) |
660W |
| Maximum Power |
750 Watt |
| Input Voltage |
200-240 Vac |
| Peak Output Capacity |
750 Watt |
| Input Frequency Range |
60-50 Hz |
| Input Current |
6 A |
| Fan Size |
120mm |
| Lighting Type |
No |
| Fan Bearing |
Fluid Dynamic Bearing |
| Warranty Details |
| Warranty |
3 Year |
| Warranty Condition |
3 Year with Burn Case |
| Additional Info |
| Country Of Origin |
Taiwan |
| Made in/ Assemble |
China |
| Feature |
The Gigabyte P750BS 750W Non-Modular 80 Plus Bronze Certified Black Power Supply is a trusty choice for anyone putting together a
solid computer without spending a fortune. This unit pushes out 750 watts with an 80 Plus Bronze rating, meaning it keeps pow |
| Others Info |
Connectors: ATX/MB 20+4 Pin x 1 : 600mm x 1, CPU/EPS 4+4 Pin x 2 : 600mm+150mm x 1, PCI-E 6+2 Pin x 4 : 500mm+150mm x 2, SATA x 4
: 500mm+150mm+150mm+150mm x 1, SATA x 3 + Peripheral x1 : 500mm+150mm+150mm+150mm x 1. |
| Specialty |
80 PLUS Bronze certified (230V EU), 120mm Silent Fluid Dynamic Bearing (FDB) fan, Soft-textured embossed cables, Single +12V rail,
OVP/OPP/SCP/UVP/OCP/OTP protection. |
