| General |
| Brand |
Gigabyte |
| Model |
Gigabyte A620M H |
| CPU |
| Chipset Brand |
AMD |
| Chipset |
AMD A620 |
| Sockets Supported |
AM5 |
| Built-in Processor |
No |
| Generation |
Not Applicable |
| Supported CPU |
Only supports AMD Ryzen processors |
| Memory & Storage Support |
| Memory Type |
DDR4 |
| Memory MHz |
6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800/ 4400 MT/s non-ECC Un-buffered DIMM |
| Memory Channel |
Dual |
| Memory Slot |
2 |
| Memory Max. |
96 GB |
| Storage Interface |
6.0Gb/s |
| M.2/SSD Expansion Slot |
1 |
| M.2/SSD Expansion Slot Details |
1 x M.2 type 2580/2280 SSDs |
| M.2/SSD Slot Gen |
Up to Gen 4 |
| Graphics |
| Graphics Chipset |
Integrated With Processor |
| PCI Express Slot |
1 x PCI Express x16 slot, 1 x PCI Express x1 slot |
| Ports |
| USB Port |
4 x USB 2.0/1.1 ports, 2 x USB 3.2 Gen 1 ports |
| VGA Port |
No |
| DVI Port |
No |
| HDMI Port |
1 |
| DisplayPort (DP) |
1 |
| SATA Port |
4 |
| Thunderbolt |
No |
| Network & Connectivity |
| LAN Chipset |
Realtek GbE LAN |
| LAN Speed (Mbps) |
10/ 100/ 1000Mbps |
| WiFi |
No |
| Bluetooth |
182 |
| Audio |
| Audio Chipset |
Realtek Audio CODEC High Definition Audio |
| Audio Channel |
7.1 |
| Software |
| Supported Operating System |
Windows 10, Windows 11 |
| Technical Info |
| Cable Management |
Front |
| Heatsink |
No |
| RGB Support |
ARGB |
| RGB Connector |
1 x Addressable LED strip header, 1 x RGB LED strip header |
| Approx. Power Consumption |
60W |
| Form Factor |
Micro-ATX |
| Warranty Details |
| Warranty |
3 Year |
| Additional Info |
| Country Of Origin |
Taiwan |
| Made in/ Assemble |
China |
| Bios Information |
| BIOS Type |
1 x 256 Mbit flash |
| BIOS Model |
AMI UEFI BIOS |
