| General |
| Brand |
DeepCool |
| Model |
PF500X |
| Series |
PF-X |
| PSU Category |
Non Modular |
| Type |
ATX12V V2.52 Non-Modular |
| Part No |
PF500X-HD |
| Physical Description |
| MTBF |
40,000 Hours |
| Form Factor |
ATX |
| Dimensions |
150 x 86 x 140mm |
| Color |
Black |
| Performance & Protection |
| Efficiency |
80% Efficiency |
| Efficiency Rating |
80 Plus |
| Power Good Signal |
100-150ms |
| Hold Up Time |
≥16ms(80% Load) |
| Protection |
OPP/OVP/SCP/OTP/OCP/UVP/SIP/NLO |
| Over Voltage Protection (OVP) |
Unmentioned |
| Over Power Protection (OPP) |
No |
| Over Current Protection (OCP) |
Yes |
| Over Temperature Protection (OTP) |
No |
| Short Circuit Protection (SCP) |
No |
| Under Voltage Protection (UVP) |
No |
| Connectors, Features & Power |
| ATX Main Connectors |
1 |
| PCIe Connectors |
2 |
| SATA Power Connectors |
3 |
| 4-Pin Peripheral Connectors |
1 |
| Maximum Power |
500 Watt |
| Input AC |
220 |
| Input Voltage |
220V |
| Input Frequency Range |
500 Watt |
| Fan Size |
120mm |
| Lighting Effect |
No |
| Lighting Type |
Not Applicable |
| Fan Bearing |
Longlife HYB |
| Warranty Details |
| Warranty |
3 Year |
| Warranty Condition |
No warranty For burn and personal damage |
| Additional Info |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Feature |
Key Features |
