| General |
| Brand |
Cudy |
| Physical Description |
| Indicators |
LED |
| Body Material |
Metal |
| Body Color |
Black |
| Form Factor |
Rackmount |
| Dimension |
440 x 207 x 44mm |
| Packet Contents |
1 x GS1028PS2, 1 x Power Cord, 1 x Installation Guide |
| Power Supply |
AC: 100 - 240V, 50/60Hz |
| Approx. Power Consumption |
32W (Max) |
| Ports & Slots |
| Number of Total Port |
26 Port |
| SFP Port |
2 |
| Gigabit Port |
26 |
| PoE Port |
No |
| SFP+ Port |
No |
| PoE+ Port |
24 |
| Technical Info |
| PoE |
Yes |
| Manageability |
Unmanaged |
| Interface(s) |
24 x Gigabit PoE+ Switch, 2 x Gigabit SFP Ports |
| Network Standards |
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x, IEEE802.3af, IEEE802.3at |
| Data Transfer Rate |
10/100/1000 Mbps |
| Switching Capacity |
56Gbps |
| OS Supported |
All OS |
| Additional Info |
| Others |
IEEE 802.3af/802.3at standard compliant, 300 watts total PoE power budget, up to 30-watt per port, 24 x GbE PoE+ Port and 2 x SFP
Port, CCTV Mode supports remote power & data feeding up to 250 meters, VLAN mode supports 24 POE+ ports isolated from each ot |
| Specialty |
24-Port PoE + 2-Port Uplink, Flexibility of Uplink Ports, Heat Dissipation, Texas Instruments PoE chipset inside, Auto-sensing tec
hnology, Lightning protection |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Warranty Details |
| Warranty |
1 Year |
| Warranty Condition |
1YEAR(Without Adapter) |
