| General | |
| Brand | ASUS |
| Model | Asus PRIME H510M-F R3.0 |
| CPU | |
| Chipset Brand | Intel |
| Chipset | Intel H470 |
| Sockets Supported | LGA1200 |
| Built-in Processor | No |
| Generation | 10th/11th |
| Supported CPU | 10th/11th11th Gen Intel Core & 10th Gen Intel Core, Pentium Gold and Celeron Processors |
| Memory & Storage Support | |
| Memory Type | DDR4 |
| Memory MHz | 3200(OC)/3000(OC)/2933/2800/2666/2400/2133. |
| Memory Channel | Dual |
| Memory Slot | 2 |
| Memory Max. | 64 GB |
| Storage Interface | 6.0Gb/s |
| M.2/SSD Expansion Slot | 1 |
| M.2/SSD Expansion Slot Details | 1 x M.2, type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes) |
| M.2/SSD Slot Gen | Up to Gen 3 |
| Graphics | |
| Graphics Chipset | Integrated With Processor |
| PCI Express Slot | 1 x PCIe 4.0/3.0 x16 slot, 1 x PCIe 3.0 x1 slot |
| Multi-GPU Support | No |
| Ports | |
| USB Port | 4 x USB 5Gbps ports (4 x Type-A), 2 x USB 2.0 ports (2 x Type-A) |
| VGA Port | No |
| DVI Port | No |
| HDMI Port | 1 |
| DisplayPort (DP) | No |
| SATA Port | 4 |
| Thunderbolt | No |
| Network & Connectivity | |
| LAN Chipset | Realtek 1Gb Ethernet |
| LAN Speed (Mbps) | 1 x Realtek 1Gb Ethernet port |
| WiFi | No |
| Bluetooth | No |
| Audio | |
| Audio Chipset | Realtek 7.1 Surround Sound High Definition Audio CODEC* |
| Audio Channel | Supports up to 24-Bit/192 kHz playback |
| Software | |
| Supported Operating System | Windows 10 |
| Technical Info | |
| Back-Connect Design | No |
| Cable Management | Front |
| Heatsink | No |
| RGB Support | No |
| Approx. Power Consumption | 60W |
| Form Factor | Micro-ATX |
| Warranty Details | |
| Warranty | 3 Year |
| Warranty Condition | 3 Year Replacement |
| Additional Info | |
| Country Of Origin | Taiwan |
| Made in/ Assemble | China |
| Feature | Intel LGA 1200 socket: Ready for 11th and 10th Gen Intel Processors, Ultrafast connectivity: PCIe 4.0, 32Gbps M.2 slot, 1Gb Ethern et and USB 5Gbps, Comprehensive cooling: PCH heatsink, 5X Protection III: Multiple hardware safeguards for all-round protecti |
| Bios Information | |
| BIOS Type | 128 Mb Flash ROM |
| BIOS Model | UEFI AMI BIOS |
