| General |
| Brand |
AFOX |
| Model |
AFOX IH310CD4-MA2-V6 |
| CPU |
| Chipset Brand |
Intel |
| Chipset |
Intel H310 |
| Sockets Supported |
LGA1151 |
| Built-in Processor |
No |
| Generation |
Ryzen 8000 Series |
| Supported CPU |
Intel i7/ i5/ i3/ Pentium, Celeron processors |
| Memory & Storage Support |
| Memory Type |
DDR4 |
| Memory MHz |
3200 / 3000/ 2800/ 2666/ 2400/ 2133 MHz |
| Memory Channel |
Dual |
| Memory Slot |
2 |
| Memory Max. |
32 GB |
| Storage Interface |
6.0Gb/s |
| M.2/SSD Expansion Slot |
1 |
| M.2/SSD Expansion Slot Details |
1 x M.2 (PCIe NVMe Gen 3 x 4 & SATA 3) |
| M.2/SSD Slot Gen |
Up to Gen 3 |
| Graphics |
| Graphics Chipset |
Intel HD Graphics support |
| PCI Express Slot |
1 x PCI Express x 16 |
| Multi-GPU Support |
No |
| Ports |
| USB Port |
2 x USB 3.0, 4 x USB 2.0, |
| VGA Port |
1 |
| DVI Port |
1 |
| HDMI Port |
1 |
| DisplayPort (DP) |
No |
| SATA Port |
6 x SATA 6Gb/s |
| Thunderbolt |
No |
| Network & Connectivity |
| LAN Chipset |
Realtek RTL8105/8106 Ethernet |
| LAN Speed (Mbps) |
Realtek RTL8105/8106 Ethernet |
| WiFi |
No |
| Bluetooth |
No |
| Audio |
| Audio Chipset |
Realtek 662 |
| Audio Channel |
6 |
| Software |
| Supported Operating System |
Windows 8 |
| Technical Info |
| Back-Connect Design |
No |
| Cable Management |
Front |
| Heatsink |
No |
| RGB Support |
No |
| Approx. Power Consumption |
60Wort |
| Form Factor |
Micro-ATX |
| Warranty Details |
| Warranty |
3 Year |
| Warranty Condition |
No warranty For burn and personal damage. |
| Additional Info |
| Country Of Origin |
China |
| Made in/ Assemble |
China |
| Feature |
High speed USB interface. High quality audio special capacitor+independent audio block LED isolation line. Greater capacity. Rapid
transmission is always ready. Rambling mainstream game world. Wonderful design rendering effect. Satisfy all your computing |
| Others Info |
Mounting: 4 mounting holes. 1 x RJ-45 LAN Port with LED. 3 x HD Audio Jacks. FSB: 2133 / 2400 / 2666 / 2800(O.C.) / 3000(O.C.) MHz |
| Bios Information |
| BIOS Model |
UEFI BIOS |
